HSD080 8-Way 8 Input XLR Multicore Cable Drum – Plastic
The HSD080 8-Way 8 input XLR Multicore Cable Drum featuring 2-core 26 AWG shielded lines with foil shield and a drain wire on each channel. All send channels are fully balanced and shielded, with XLR connectors throughout. It is suitable for connecting performers on stage or in a recording studio to a mixing desk.
Specifications
| Model | Channel | Input | Return | Cable Type | Length |
| HSD080L10 | 8 | 8 x XLR(F) | MUC108 | 10M | |
| HSD080L15 | 8 | 8 x XLR(F) | MUC108 | 15M | |
| HSD080L20 | 8 | 8 x XLR(F) | MUC108 | 20M | |
| HSD080L25 | 8 | 8 x XLR(F) | MUC108 | 25M |
- 8 Balanced XLR send Channels
- Oxygen-free copper conductor
- Shielded Twisted Pair with foil and drain wire
- Rugged plastic drum mounted on a steel frame with integral carry handle
- Numbered XLR connectors for easy identification
- Heavy-duty heat shrink over the entire length of fanout
- Cable management disk on fanout
- XLR tails with braided outer for durability – blue color
