DC502 4 Pair 24AWG CAT5e UTP Networking Cable – Solid Conductor

Specifications

Cable model	DC501	DC502	DC503	DC504
Type of cable	CAT5e UTP Network cable	CAT5e UTP Network cable	CAT5e FTP Network cable	CAT5e STP Network cable
Conductor material	Bare stranded copper	Solid bare copper	Solid bare copper	Solid bare copper
Structure of conductor	7 x 0.2mm	1 x 0.51mm	1 x 0.51mm	1 x 0.51mm
Conductor section	0.22 mm²	0.20 mm²	0.20 mm²	0.20 mm²
American wire gauge	24 AWG	24 AWG	24 AWG	24 AWG
Insulation material	HDPE Ø0.98	HDPE Ø0.98	HDPE Ø0.98	HDPE Ø0.98
Insulation color	Orange / White & Orange ;Green / White & Green ; Blue / White & Blue ; Brown / White & Brown	Orange / White & Orange ;Green / White & Green ; Blue / White & Blue ; Brown / White & Brown	Orange / White & Orange ;Green / White & Green ; Blue / White & Blue ; Brown / White & Brown	Orange / White & Orange ;Green / White & Green ; Blue / White & Blue ; Brown / White & Brown
Number of cores	8 (4 pairs)	8 (4 pairs)	8 (4 pairs)	8 (4 pairs)
Shielding	No	No	AL/PET foil	AL/PET foil + AL/Mg wire braided
Outer Jacket	PVC, Black	PVC, Black	PVC, Black	PVC, Black
Outer Jacket O.D	Ø5.2	Ø5.2	Ø6.0	Ø6.2
Electrical characteristics
Conductor resistance-1000M	≤ 87 ohm	≤ 90 ohm	≤ 90 ohm	≤ 90 ohm
Rated voltage	300 V	300 V	300 V	300 V
Characteristic impedance	100 Ω ± 15	100 Ω ± 15	100 Ω ± 15	100 Ω ± 15
Operating capacity	48 pF/m	48 pF/m	48 pF/m	48 pF/m
Propagation delay	45 ns/100m @ 1-100 MHz	45 ns/100m @ 1-100 MHz	45 ns/100m @ 1-100 MHz	45 ns/100m @ 1-100 MHz
Delay skew	0.25 nsec/m	0.25 nsec/m	0.25 nsec/m	0.25 nsec/m
Mechanical characteristics
Tensile strength	100 N	100 N	100 N	100 N
Temperature range	fixed installation		-40 °C to +80 °C
Temperature range	flexible installation		-20 °C to +70 °C
Bending radius	fixed installation		8 x outer diameter
Bending radius	flexible installation		10 x outer diameter

Packaging

Plastic Reel,Plywood Reel,Cardboard Reel,Shrink-plastic packaging;
Length: 305M
Lower and upper lengths according to availability. Special packaging on request.
