CDX02 Classic 5-pin Digital Lighting DMX Cable with 5-pin XLR Female to 5-pin XLR Male – 4 core Dual Shielding 110Ω Cable
The CDX02 Classic series 5-pin XLR female to 5-pin XLR male DMX cable featuring high quality XLR connectors, and the ultra flexible dual shielding 4-core DMX cable.
It is suitable for carrying the DMX512 digital data protocol, commonly used for stage lighting and effects equipment such as digital light controllers, consoles, dimmers, lasers and fog machines.
Specifications
- Connector 1 : 5-pin XLR female connector, nickel, XLR5F002
- Connector 2 : 5-pin XLR male connector, nickel, XLR5M002
- Cable Type: 24 AWG 4-core DMX cable, dual shielding, DL12
Packaging
- Sleeve, plastic bag, paper box and blister packing are available;
- Special packaging on request.
- Oxygen free copper (OFC)
- 24 AWG thin and dense stranded conductors
- 4C*20/0.12mm + 16*8/0.12mm (Braided shield)
- 110Ω characteristic impedance
- Ultra flexible PVC jacket
- 8.0 mm (Ø) outer diameter, black
- 5-pin XLR connector, Nickel
